A204 Pressure Vessel Steel Plate

A204/SA-204 steel is a carbon molybdenum alloy steel with a nominal composition of C-0.5Mo. According to this standard specification, steel plates can be divided into three different strength grades: Grade A, Grade B and grade C.

Telephone: +86 18153248286

E-mail: yang@xycnmetal.com

Submit requirements

Online consultation



： Home > Product > Carbon Steel > Carbon steel plate > A204 Pressure Vessel Steel Plate

Specification parameter

Spot inventory

Product testing

Steel packing

PRODUCT INFORMATION

The maximum thickness of ASTM A204 plates is limited only by the composition’s ability to meet the specified mechanical property requirements. However, current practice normally limits the maximum thickness of plates made of Grade A, Grade B, and Grade C steel to 6′′ [150 mm], 4′′ [100 mm], respectively. Plates under 1-1/2″ [40 mm] in thickness must be supplied in the as-rolled condition. Plates over 1-1/2″ [40 mm] in thickness may be normalized or stress relieved, or both.

Product Parameters

Product Name	A204 Pressure Vessel Steel Plate
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

A204	Upper limit of Chemical Element Content (%)
A204	C	Si	Mn	P	S	Mo
Class A	0.18-0.25	0.13-0.45	0.90-0.98	0.035	0.035	0.45-0.60
Class B	0.20-0.27	0.13-0.45	0.90-0.98	0.035	0.035	0.45-0.60
Class C	0.23-0.28	0.13-0.45	0.90-0.98	0.035	0.035	0.45-0.60

Mechanical Properties

A204	Tensile Strength kis[MPa]	Yield Strength kis[MPa]	ElongationGauge length 8in.[200mm],%	ElongationGauge length 2in.[50mm],%
GradeA	70-90 [485-620]	37 [255]	19	23
GradeB	75-95 [515-655]	40 [275]	17	21
GradeC	75-95 [515-655]	43 [295]	16	20

Physical Performance

Physical Performance	Metric	Imperial
Density	7.80g/cc	0.282 lb/in³

Scope of Application

ASTM A204 boiler vessel plate is widely used in petroleum, chemical industry, power station, boiler and other industries, used in the manufacture of reactors, heat exchangers, separators, spherical tanks, liquefied gas, nuclear reactor pressure vessels, boiler drum steam, liquefied petroleum gas, hydropower stations, high pressure pipelines, etc.
