Titanium alloy tube

Dedicated to creating first-class quality alloy steel products: alloy plate, alloy pipe, alloy round steel, alloy flange.Its materials include: Hastelloy alloy, Ni-Cr alloy, Ink Ni-Cr alloy, Inconel alloy, Monel alloy, titanium alloy and so on.We pursue first-class quality, and professional is the company's unremitting pursuit.

Telephone: +86 18153248286

E-mail: yang@xycnmetal.com

Submit requirements

Online consultation



： Home > Product > Alloy Steel > Alloy pipe > Titanium alloy tube

Specification parameter

Spot inventory

Product testing

Steel packing

PRODUCT INFORMATION

Outer Diameter	6-2500mm， (3/8"-100")
Thickness	0.3-150mm，(SCH10-XXS)
Length:	2000mm, 2500mm, 3000mm, 5800mm,6000mm,12000mm，etc
Standard:	ASTM，JIS, AISI, GB, DIN, EN
Certification:	ISO, SGS

ASTM/ASME		GB	JIS	Element Content（wt%）						Mechanical Properties
				N,max	C,max	H，max	Fe,max	O,max	Others	Strength Of Extension	Ductility
										Mpa,min	%，min
Pure Titanium	Gr.1	TA1	Class1	0.03	0.08	0.015	0.2	0.18		240	24
	Gr.2	TA2	Class2	0.03	0.08	0.015	0.3	0.25		345	20
	Gr.3	TA3	Class3	0.05	0.08	0.015	0.3	0.35		450	18
	Gr.4	TA4	Class4	0.05	0.08	0.015	0.5	0.4		550	15
Titanium Alloy	Gr.5	TC4	Class60	0.05	0.08	0.015	0.4	0.2	AI:5.5-6.75	895	10
		Ti-6A1-4V							V:3.5-4.5
	Gr.7	TA9	Class12	0.03	0.08	0.015	0.3	0.25	Pd:0.12-0.25	345	20
	Gr.9	TC2	Class61	0.03	0.08	0.015	0.25	0.15	AI:2.5-3.5	620	15
									V:2.0-3.0
	Gr.11	TA9-1	Class11	0.03	0.08	0.015	0.2	0.18	Pd:0.12-0.25	240	24
	Gr.23	TC4 ELI	Class60E	0.03	0.08	0.0125	0.25	0.13	AI:5.5-6.5	828	10

Steel plate flaw detection

Mechanical property test

Tensile performance test

To ensure that each post and each process of the packaging operation process have evidence to rely on, but also clear the packaging material quality and packaging operation quality control points, to ensure that the quality of packaging products is controlled, our product delivery pass rate of 100%, won high praise from customers.

Specification measurement

Coating thickness detection

Component test

Check the data again before delivery

Training staff to repeatedly bundle and other packaging basic operation skills, to further reflect our company's "high rhythm, high efficiency, high quality" service purpose.

We will package and load the car according to the needs of customers to ensure that the goods are finally delivered to your hands perfectly.

PACKAGING
